PX BASEC 2 Core Cable - Grey

The PX BASEC 2 Core Cable – Grey 1.5mm² x 50m is a high-quality, general-purpose fixed wiring cable designed for domestic and light commercial electrical installations. Featuring two colour-coded copper conductors (Brown and Blue) encased in a durable grey PVC sheath, this cable is ideal for use in lighting circuits, low-power radial circuits, and other applications where a CPC (Earth) conductor is not required or is provided separately.

This product is BASEC approved and manufactured in accordance with British Standard BS 6004, ensuring reliable performance and full compliance with UK wiring regulations. The 1.5mm² conductors make it well-suited for circuits carrying up to approximately 20 amps, depending on installation conditions.

Key Features:

1. Two Core Cable (Brown & Blue):
   Includes Live and Neutral conductors, suitable for applications where no Earth is required or provided separately.
2. Conductor Size: 1.5mm²:
   Ideal for standard lighting and small power circuits.
3. BASEC Approved:
   Complies with BS 6004, ensuring full UK regulation compliance and trusted electrical safety.
4. Grey PVC Sheath:
   Flat and flexible outer layer for easy routing, stripping, and installation.
5. Versatile & Reliable:
   Suitable for a wide range of indoor applications in dry environments.

Product Specifications:

1. Product Name: PX BASEC 2 Core Cable
2. Core Count: 2 (Live – Brown, Neutral – Blue)
3. Core Size: 1.5mm²
4. Cable Type: Fixed wiring
5. Outer Sheath Colour: Grey PVC
6. Conductor Type: Stranded copper
7. Length: 50 metres
8. Rated Voltage: 300/500V
9. Max Current Rating: Approx. 20A (depending on installation conditions)
10. Standards Compliance: BS 6004 | BASEC Certified
11. Boxed Weight: 4.2kg

Typical Applications:

1. Indoor lighting circuits
2. Radial circuits for low-load equipment
3. Control and signal wiring
4. Circuits where CPC is provided separately or not required (e.g., Class II appliances)

Installation Notes:

1. To be installed by a qualified electrician following IET Wiring Regulations (BS 7671).
2. For indoor use in dry locations – not suitable for outdoor or direct underground installation without conduit.
3. Not recommended for use where a protective conductor (Earth) is required unless installed with a separate CPC.
4. Route through conduit or trunking if exposed to potential mechanical damage.

FAQs (Frequently Asked Questions):

Q: Can I use this cable for lighting?
A: Yes. 1.5mm² is standard for lighting circuits, especially where no Earth is needed or it’s provided separately.

Q: Is this cable earthed?
A: No, it contains only two conductors—Live and Neutral. A separate Earth must be installed if required.

Q: Is this cable BASEC certified?
A: Yes, it is BASEC approved, ensuring quality, safety, and regulatory compliance.

Q: Can it be used in bathrooms or kitchens?
A: Only in compliance with electrical regulations and provided it's properly protected and the application does not require a CPC within the cable.

Q: Is it flexible?
A: It uses stranded copper conductors, offering moderate flexibility for routing through walls or conduit.

Warranty Information:

This cable is backed by a manufacturer’s warranty covering material and manufacturing defects under normal usage conditions. The warranty is void if the cable is damaged due to incorrect installation, unsuitable environmental exposure, or misuse.

Refer to the manufacturer’s guidelines for full warranty terms and support.

Conclusion:
The PX BASEC 2 Core Cable – Grey 1.5mm² x 50m is a safe, regulation-compliant solution for general fixed wiring tasks in homes and light commercial properties. Its BASEC certification, durable PVC sheath, and standard 1.5mm² cores make it ideal for lighting and signal applications where a CPC is not required, delivering performance and peace of mind for professional installations
