PX LSHF Solar Cable 4mmx100m

The PX LSHF Solar Cable 4mm² x 100m is a high-performance, Low Smoke Halogen-Free (LSHF) cable specifically engineered for solar photovoltaic (PV) systems. Designed to provide safe, efficient, and long-lasting performance in both residential and commercial solar installations, this cable ensures the secure transmission of DC electricity between solar panels, inverters, and associated equipment.

Built with UV, ozone, and weather-resistant materials, this 4mm² solar cable is suitable for indoor and outdoor installation, including rooftops and cable trays. It meets the stringent LSHF standard, reducing the emission of toxic gases and smoke in the event of fire, making it especially suitable for installation in populated or enclosed environments.

With high temperature resistance, superior insulation integrity, and durable construction, this cable ensures excellent performance over decades of solar energy production.

Key Features:

1. Low Smoke Halogen-Free (LSHF):
   Minimises toxic smoke and halogen emissions during fire, enhancing safety in enclosed or public spaces.
2. UV & Weather Resistant:
   Built to withstand intense sunlight, moisture, ozone, and environmental stress in outdoor conditions.
3. Durable DC Power Transmission:
   Designed for solar PV applications, with excellent electrical conductivity and mechanical strength.
4. Long-Term Thermal Stability:
   Suitable for continuous operating temperatures up to 120°C, ensuring reliability in hot climates and on rooftops.
5. Flexible and Easy to Install:
   Allows for neat routing and simplified installation, even in complex layouts or tight spaces.
6. Complies with International Standards:
   Manufactured in line with EN 50618 / IEC 62930, ensuring performance, safety, and compatibility across PV systems.

Product Specifications:

• Product Name: PX LSHF Solar Cable
• Length: 100 metres
• Conductor Size: 4.0mm²
• Outer Sheath Material: LSHF (Low Smoke Halogen-Free), UV-resistant
• Voltage Rating: Up to 1.5kV DC (IEC)
• Temperature Range: –40°C to +120°C (short circuit up to 200°C)
• Colour: Typically Black or Red (confirm for product variant)
• Standards Compliance: EN 50618 / IEC 62930 / RoHS / CPR Certified
• Core Type: Flexible stranded copper conductor

Boxed Dimensions:

1. Width: 24.0cm
2. Depth: 15.0cm
3. Boxed Weight: 6.4kg

Recommended Applications:

1. Photovoltaic (PV) Solar Panel Installations
2. DC connections between solar modules and inverters
3. Battery banks, solar combiner boxes, and charge controllers
4. Suitable for use in buildings, rooftops, solar farms, and off-grid systems
5. Cable trays, conduit systems, and exposed outdoor runs

Installation Notes:

1. Suitable for fixed installation, in both indoor and outdoor environments.
2. Ensure correct polarity and routing to avoid DC losses and interference.
3. Avoid sharp bends or mechanical damage during installation.
4. Double insulation may be required for exposed installations depending on local regulations.

FAQs (Frequently Asked Questions):

Q: What does LSHF mean?
A: LSHF (Low Smoke Halogen-Free) materials emit minimal smoke and zero halogen gases in a fire, reducing risk of toxic inhalation and equipment corrosion.

Q: Is this cable suitable for rooftop solar systems?
A: Yes. It is UV and weather resistant, making it perfect for use on rooftops and outdoor systems.

Q: Can it be used underground?
A: It may be used in ducted or conduit-protected underground installations, but direct burial is not recommended without mechanical protection.

Q: Is the cable double insulated?
A: PX Solar Cables typically meet EN 50618, which requires thick-walled insulation for outdoor durability, acting similarly to double insulation.

Q: What is the current rating of 4mm² solar cable?
A: Approx. 55–70A in free air depending on installation method and ambient conditions (check with local regulations or standards for exact values).

Warranty Information:

PX Solar Cables come with a manufacturer-backed warranty, typically ranging from 10 to 25 years depending on the supplier and system usage. The warranty ensures performance integrity, resistance to weathering, and material quality under normal operating conditions. Exclusions apply for improper handling, overloading, or installation errors.

For specific warranty coverage, consult the product packaging or manufacturer’s documentation.

Conclusion:
The PX LSHF Solar Cable 4mm² x 100m delivers efficient, safe, and long-lasting connectivity for solar installations. With its halogen-free insulation, weatherproof properties, and solar-grade construction, this cable is a reliable and future-proof solution for energy professionals and sustainable system builders.
